ZONESUN ZS-FAL180D Tabletop Liquid Filling Capping Labeling Line
This compact tabletop production line integrates liquid filling, bottle capping, and double-sided labeling into one efficient system. Ideal for small-scale operations, it saves space while delivering professional automation. Widely used in food, cosmetics, daily chemical, and pharmaceutical industries, it helps streamline your workflow and boost productivity. Customizable to suit various bottle types, caps, and materials, this machine is a smart solution for growing businesses.
Power Supply 110/220V, 50–60 Hz
Maximum Flow Velocity 5500 ml/min (per nozzle, based on water)
Working Speed 1500–3000 bottles/hour (depends on bottle size & liquid)
Air Pressure 0.3–0.4 MPa
Filling Accuracy ≤ ±1% (for water)
Diameter of Filling Nozzle 6 mm / 8 mm
Delay Range 0.01–999.9 s
Count Range 1–99,999 times
Net Weight 37 kg
Package Size 1110 × 650 × 420 mm
Gross Weight 50.5 kg
Filling Volume 3–1000 ml (220V) / 3–500 ml (110V)
Air Compressor Connector Size Outer Diameter 8 mm
Bottle Height <220 mm (customizable, max height 300 mm)
Bottle Height 60–270 mm
Bottle Cap Diameter 18–70 mm
Working Speed 20–40 bottles/min (depends on bottle & cap size)
Working Voltage AC 220V / 110V, 50–60 Hz
Working Pressure 0.4–0.6 MPa
Machine Size 1120 × 580 × 1110 mm
Net Weight 65.5 kg
Conveyor Length 1110 mm
Gross Weight 97.5 kg
Package Size 1160 × 610 × 1140 mm
Air Compressor Connector Size Outer Diameter 8 mm
Voltage 110V–60Hz / 220V–50Hz
Working Speed 20–50 bottles/min
Suitable Labeling Size Width: 15–140 mm / Length: 25–300 mm
Roll Inner Diameter Φ76 mm
Roll Outer Diameter Φ350 mm
Suitable Bottle Diameter ≤100 mm
Net Weight 95.5 kg
Package Size 1270 × 530 × 820 mm
Gross Weight 125 kg
Original: $6,500.00
-70%$6,500.00
$1,950.00Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
This compact tabletop production line integrates liquid filling, bottle capping, and double-sided labeling into one efficient system. Ideal for small-scale operations, it saves space while delivering professional automation. Widely used in food, cosmetics, daily chemical, and pharmaceutical industries, it helps streamline your workflow and boost productivity. Customizable to suit various bottle types, caps, and materials, this machine is a smart solution for growing businesses.
Power Supply 110/220V, 50–60 Hz
Maximum Flow Velocity 5500 ml/min (per nozzle, based on water)
Working Speed 1500–3000 bottles/hour (depends on bottle size & liquid)
Air Pressure 0.3–0.4 MPa
Filling Accuracy ≤ ±1% (for water)
Diameter of Filling Nozzle 6 mm / 8 mm
Delay Range 0.01–999.9 s
Count Range 1–99,999 times
Net Weight 37 kg
Package Size 1110 × 650 × 420 mm
Gross Weight 50.5 kg
Filling Volume 3–1000 ml (220V) / 3–500 ml (110V)
Air Compressor Connector Size Outer Diameter 8 mm
Bottle Height <220 mm (customizable, max height 300 mm)
Bottle Height 60–270 mm
Bottle Cap Diameter 18–70 mm
Working Speed 20–40 bottles/min (depends on bottle & cap size)
Working Voltage AC 220V / 110V, 50–60 Hz
Working Pressure 0.4–0.6 MPa
Machine Size 1120 × 580 × 1110 mm
Net Weight 65.5 kg
Conveyor Length 1110 mm
Gross Weight 97.5 kg
Package Size 1160 × 610 × 1140 mm
Air Compressor Connector Size Outer Diameter 8 mm
Voltage 110V–60Hz / 220V–50Hz
Working Speed 20–50 bottles/min
Suitable Labeling Size Width: 15–140 mm / Length: 25–300 mm
Roll Inner Diameter Φ76 mm
Roll Outer Diameter Φ350 mm
Suitable Bottle Diameter ≤100 mm
Net Weight 95.5 kg
Package Size 1270 × 530 × 820 mm
Gross Weight 125 kg
